ER101

ER101 is suitable for medium-sized glamping sites(more than 10 tents). It is common practice to associate the activity hall with the entire glamping hotel making ER101 an open space for WiFi, eating, drinking, reading, and socializing. It also serves as an additional booking and information center for all extra services.


*If the natural environment of your campsite is favorable, we recommend the ERX101.

技术参数
尺寸参数
帐篷尺寸
11m x 17m
室内尺寸
8m x 14m
外部高度(顶高)
4.7m
内部高度(顶高/边高)
3.2m / 2.4m
正门尺寸/数量
2.1m x 2.5m * 4
玻璃门尺寸/数量
2.1m x 2.8m * 2
窗户尺寸/数量
1.8m x 1.5m * 4
结构参数
结构材料
菠萝格防腐木
结构管径
90mm
连接件材料
防锈钢材
连接方式
自攻螺丝
环境适应
抗风等级
9级
适温条件
-20℃~50℃
屋面载荷
15kg/㎡
使用寿命
10年
篷布参数
外帐材料
750g-PVC涂层布
外帐颜色
卡其色(多色可选)
外帐性能
•抗撕裂 •阻燃 •抗UV •防腐蚀
固定方式
•铝压条 •拉绳
内帐参数
内帐材料
370g-牛津布
内帐颜色
米黄色(多色可选)
内帐性能
•阻燃 •抗UV •防霉抗菌
固定方式
•套管 •绑带
内帐与地面连接处理方式
•木压条 •防水胶
门窗材料
牛津布 / 透明PVC
开合方式
拉链 / 魔术贴
防蚊沙帘
标配
平台参数(选配)
平台尺寸
4.7m x 7.2m
平台结构
镀锌钢材
结构尺寸
100 x 80 x 4mm
连接方式
焊接(可螺栓)
平台层板
进口-樟子松
层板规格
4000 x 100 x 25mm
精装木地板(室内)
1210 x 183 x 12mm
卫生间参数(选配)
卫生间整体尺寸
2.6m x 1.5m
墙体厚度
70mm
墙体饰面(室内)
15mm实木板
氛围灯(室内)
墙-上方
墙体饰面(卫内)
4mm铝板
吊顶饰面(卫内)
4mm铝板
卫门材料
实木门
浴室尺寸
0.9m x 0.9m
浴室地面
岩板
浴室隔断
钢化玻璃
卫生间配套
•洗手台 •镜面 •马桶 •花洒
卫生间设施
•水电系统 •照明系统 •排气系统
